Unica 520

Your Most Trusted Ally
in the Operating Room

The Only Surgical Light Without Glare

UNICA 520 delivers deep, stratified illumination that is completely glare-free, ensuring optimal visual comfort during surgical procedures. The light beam passes through a precision-engineered diffusion screen with a calibrated surface roughness index, allowing it to collimate and layer the light evenly.

Equipped with RIMSA’s patented 2R Double Reflection System, UNICA 520 maximizes the light-emitting surface to produce high-performance illumination with depth, clarity, and shadow-free precision—reaching up to 160,000 Lux while remaining entirely glare-free.

UNICA 520 Surgical Light

The UNICA 520 surgical lamp by RIMSA delivers clean, white light using only white LEDs across 7 adjustable color temperatures, eliminating the risk of unwanted colored shadows. Designed for precision and ease of use, its slim reflector is highly maneuverable, while an advanced electronic system activates a secondary group of LEDs, reflected through optical lenses to create two distinct light field diameters.

Key features include:
– Glare-free illumination with optical-grade PMMA lenses and high-reflective mirrors
– Endoled Function: enables soft ambient light for a calming, low-intensity lighting environment during specific phases of surgery.

Features

Compensation Area

3D Light

Double Reflection

rimsa - always-on-focus light

Always-in-Focus Illumination

Accessories

rimsa - double yoke icon

Double Yoke

rimsa - full hd wire icon

FULL HD Wire

rimsa - full hd wifi icon

FULL HD WiFi

rimsa - 4k wire icon

4K Wire

rimsa - monitor support arm icon

Monitor Support Arm

rimsa - wall panel control icon

Wall Control Panel

rimsa - battery group icon

Battery Group

rimsa - ir remote control icon

IR Remote Control

rimsa - full integration system icon

Full Integration System

Sustainability certificate

UNICA 520 Available Configurations

Technical Specifications

Illuminance at 1 Meter (Ec)

160.000 Lux

Lamp Head Diameter

52 cm

Color Temperature (7 Selectable Levels / continue)

3.800-5.400K

Light Field Diameter

170-380 mm

LED Lifespan

> 60.000 hours

Light Intensity Control

3-100%

Engineered to Perform from Every Angle

Need More Information?

  • Previous ProjectUnica 860

Compensation Area

For specific types of surgery such as thoracic surgery, abdominal surgery, and cesarean delivery, it is essential to have a wide and high-intensity light field. An additional optical system allows the illuminated area to expand up to 30 cm, maintaining a peripheral light intensity of 6,000 Lux while keeping the central intensity (Ec) unchanged.

3D Light

At the center of the lamp, an additional module of 9 LEDs has been integrated, equipped with special reflectors designed to project light deeply. The 3D deep light ensures excellent three-dimensional illumination, especially within body cavities, assisting the surgeon with optimal visibility during procedures.

Double Reflection

In 2017, RIMSA patented its innovative Double Reflection technology, designed to maximize the light emission surface. This breakthrough enables the UNICA series and selected veterinary lamps to deliver exceptional surgical lighting performance with completely glare-free illumination.
